Epson Expression 10000XL Service Manual

Expression 10000XL Revision A
PRODUCT DESCRIPTION Basic Specifications 10
1.1.2 TPU Product Features
The following provides the main features of the ES-10000G own transparent document
unit.

Document size: Max. 309 x 420mm (12.2inch x 16.5inch)

Xenon fluorescent lamps specifically used for positive and negative films,
respectively

Reflective documents can also be scanned with the transparent document unit
attached

Easily detachable/attachable document mat

Hinges in easily detachable/attachable floating system and achieving a free stop of
the TPU unit

Ultra-thin design

Four dedicated film holders supplied

35mm strip film holder

35mm slide film holder

4 x 5 inch film holder

Brownie film holder
1.2 Basic Specifications
1.2.1 General Specifications

Type : Desktop A3 flat-bed color image scanner

Scanning system : Carriage moving type document scanning system

Sensor : Alternative 6-line color CCD line sensor

Document size : A3

Maximum effective pixels : 29,280 (main) x 41,280 (sub) pixels (2400dpi)

Maximum effective area

Document tray scan : 12.2 x 17.2 inches (310 x 437mm)

ADF scan : 11.7 x 17.0 inches (297 x 432mm)

TPU scan : 12.2 x 16.5 inches (309 x 420mm)

Scanning resolution : Main 2400dpi
Sub 4800dpi (micro-step drive)

Output resolution : 50 - 12800dpi (1 dpi step)
(12800 dpi is achieved by 6400 dpi x 200%)

Pixel Depth : 16-bit input for each pixel/each color
1 to 16 bit output

Focus control : Auto focus by right-angle mirror control
(-2mm to +6mm) Manual setting enabled

Scanning speed

1200 dpi scan mode
Line Art About 2.7msec/line
256 levels of Grayscale About 2.7msec/line
Color About8.0msec/line

Epson Expression 10000XL Specifications

Resolution

optical resolution	2400 dpi
maximum resolution with Micro Step Drive technology	2400 x 4800 dpi
interpolated resolution	12, 800 x 12, 800 dpi

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without optional unit	45W
power consumption operating with optional unit	55W
power consumption sleep mode without optional unit	6W

Operating Environment

operating temperature	41ºF to 95ºF (5ºC to 35ºC)
operating humidity	10% to 80% (no condensation)
storage humidity	10% to 85% (no condensation)

Interface and Connectivity

interface	USB 1.1/2.0, IEEE 1394 (FireWire), optional Ethernet
system compatibility	Windows 98SE, 2000 Me, XP; Macintosh OS 9.1 or later

Weight and Dimensions

maximum scan area	12.2" x 17.2" (310mm x 437mm)
width	25.8" (656mm)
depth	18.0" (458mm)
height	6.2" (158mm)
weight	28.7 lb (13 kg approx.)
