Epson Expression 10000XL Service Manual

Expression 10000XL Revision A
APPENDIX Parts List 89
7.4 Parts List
Table 7-1. Main Parts List
Ref No. Part Name
NON FIG APPLICATION CD-ROM,J
NON FIG CD-ROM SOFTWARE
NON FIG USER'S GUIDE
1 ASY-CVR-PLATEN-39
221 SCR040120FDBB
400 AC CABLE
5 ASY-CVR-UP-39
6 GID-SET-SUB-39
7 GID-OPT
76 LABEL, MODEL NAME
8 CVR-SCR-UPPER-39
9 SEL-PLT-LOGO-39
15 PBA-MAIN
16 PBA-SUB
25 PWS-DU2L3B158
10 ASY-CRG
14 BOX-BRD-UP
18 ASM-PANEL
19 ASM-MOT
26 ASM-FG
27 ASY-BOX-PS-39
28 CBP-POWER
29 ASY-TEN-L
30 ASY-TEN-D
31 SP-TEN-MOT
32 MOT-17PY-Z002-ASSY
33 BELTST1027060
34 BELTS5580080
35 PLY-ST1162ST5536
36 FNLG-S
38 SCR-DMPR-CR
39 BKT-MOT
40 HLDR-CDS
41 TLP1241(C5)
42 LVR-CDS
43 SP-TEN-CDS
44 CRG-LOCK-39
45 CRG-LOCK-LVR-39
46 ASM-SENS
48 ASM-ACLINE
49 ARM-SW
51 SW-PS
52 FLTR-IN
53 FLTR-OUT
54 FAN-1606KL-05W-B30
57 SHT-PS-LO
58 GUIDE-RAIL
59 CVR-MOUNT
60 LEG-16*16*3
61 PBA-PANEL
62 RLMC-05T V0
63 RLMC-01T V0
64 T18MR
64 T18MR
65 CVR-LOWER-39
70 GUIDE-RAIL
72 CVR-SENSOR-39
78 STG-5-5-68
79 STG-2-12-25
80 HLDR-CORE-L
81 CVR-BOX-LO-R
82 CVR-BOX-LO-L
83 SHT-CVR-LO-S
Table 7-1. Main Parts List
Ref No. Part Name

Epson Expression 10000XL Specifications

Resolution

optical resolution	2400 dpi
maximum resolution with Micro Step Drive technology	2400 x 4800 dpi
interpolated resolution	12, 800 x 12, 800 dpi

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without optional unit	45W
power consumption operating with optional unit	55W
power consumption sleep mode without optional unit	6W

Operating Environment

operating temperature	41ºF to 95ºF (5ºC to 35ºC)
operating humidity	10% to 80% (no condensation)
storage humidity	10% to 85% (no condensation)

Interface and Connectivity

interface	USB 1.1/2.0, IEEE 1394 (FireWire), optional Ethernet
system compatibility	Windows 98SE, 2000 Me, XP; Macintosh OS 9.1 or later

Weight and Dimensions

maximum scan area	12.2" x 17.2" (310mm x 437mm)
width	25.8" (656mm)
depth	18.0" (458mm)
height	6.2" (158mm)
weight	28.7 lb (13 kg approx.)
