Epson Expression 10000XL Service Manual

Expression 10000XL Revision A
DISASSEMBLY/ASSEMBLY Overview 33
4.1 Overview
This chapter explains the procedures for disassembling the major units and parts of the
product. Unless otherwise explained, reassembly should be carried out in the reverse
order of the disassembly procedure. When you have to remove any units or
components that are not described in this chapter, refer the exploded diagram in the
Appendix. Before starting disassembly, always read the precautions described in the
next section.
4.1.1 Precautions
Before starting the disassembly or reassembly of the product, always read the
following precautions given under the headings "WARNING" and "CAUTION".
W A R N I N G

Before disassembling or reassembling this product, always
disconnect the Power Cable and Interface Cable. However,
when you have to work with power ON for voltage
measurement, etc., use extreme care not to get an electric shock
and do the work in accordance with the procedure given in this
manual.

To prevent your hands from being cut by sharp edges, always
wear gloves before starting disassembly/reassembly.

When touching any internal components, use a static electricity
discharger such as anti-static wrist straps, and handle them
carefully to protect the microprocessors and circuits.
C A U T I O N

Provide sufficient work space for disassembling and
reassembling.

Always use only the recommended tools for disassembly,
reassembly and adjustment.

Be sure to tighten the screws to the specified torque.

Use the specified grease for lubrication. (Refer to Chapter 6 for
details)

Epson Expression 10000XL Specifications

Resolution

optical resolution	2400 dpi
maximum resolution with Micro Step Drive technology	2400 x 4800 dpi
interpolated resolution	12, 800 x 12, 800 dpi

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without optional unit	45W
power consumption operating with optional unit	55W
power consumption sleep mode without optional unit	6W

Operating Environment

operating temperature	41ºF to 95ºF (5ºC to 35ºC)
operating humidity	10% to 80% (no condensation)
storage humidity	10% to 85% (no condensation)

Interface and Connectivity

interface	USB 1.1/2.0, IEEE 1394 (FireWire), optional Ethernet
system compatibility	Windows 98SE, 2000 Me, XP; Macintosh OS 9.1 or later

Weight and Dimensions

maximum scan area	12.2" x 17.2" (310mm x 437mm)
width	25.8" (656mm)
depth	18.0" (458mm)
height	6.2" (158mm)
weight	28.7 lb (13 kg approx.)
