Epson Expression 10000XL Service Manual

Expression 10000XL Revision A
PRODUCT DESCRIPTION Basic Specifications 12

Image processing
Binary output : Fixed threshold value simple binary output,
TET processing
Halftone processing output : 2-state, 4-state output
3 average error-minimized halftone types (A,B,C)
4 dither types (A,B,C,D)
2 user-defined dither types (A,B)
Area separation processing (AAS)

Compatible OS

Windows
[USB1.1] Windows 98/Me/2000 Professional/XP Home
Edition, Professional
[USB2.0] Windows 2000 Professional/XP Home
Edition, Professional
[IEEE1394] Windows 2000 Professional/XP Home
Edition, Professional

Macintosh
[USB1.1] Mac OS 9.1, Mac OS X 10.2 or later (10.0-10.1
are not supported)
[USB2.0] Mac OS 10.2.7or later
[FireWire] Mac OS 9.1, Mac OS X 10.2or later(10.0-10.1
are not supported)

Rewritable firmware
The firmware is rewritable by downloading from PC via USB2.0.
1.2.4 Electrical Performance

Main unit

Power supply voltage : Universal power supply
Rating: AC100-120V, AC220-240V
(AC ± 10% V)

Power supply frequency : Rating : 50 to 60Hz (49.5 to 60.5Hz)

Rated power : Operating : About 45W
(when option is not attached)
About 55W
(when option is attached)
Standby : About 6W
(when option is not attached)

Insulation resistance : 10MΩ or more
(at 500VDC between AC line and chassis)

Dielectric withstand voltage: AC1500V, 1 min.(between AC line and chassis)

TPU

Power supply voltage : DC+24V, A+5V (supplied from main unit)

Rated power : DC+24V, A1.3A
DC+5V, A0.3A
1.2.5 Compliant Standards

Electromagnetic interference resistance : Compliant with VCCI Class B

Immunity : JEIDA52-1998

Leakage current : 0.25mA or less

Power supply harmonics : Compliant with Harmonic Suppression
Guideline

Environmental protection : Compliant with International Energy
Star Program

Epson Expression 10000XL Specifications

Resolution

optical resolution	2400 dpi
maximum resolution with Micro Step Drive technology	2400 x 4800 dpi
interpolated resolution	12, 800 x 12, 800 dpi

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without optional unit	45W
power consumption operating with optional unit	55W
power consumption sleep mode without optional unit	6W

Operating Environment

operating temperature	41ºF to 95ºF (5ºC to 35ºC)
operating humidity	10% to 80% (no condensation)
storage humidity	10% to 85% (no condensation)

Interface and Connectivity

interface	USB 1.1/2.0, IEEE 1394 (FireWire), optional Ethernet
system compatibility	Windows 98SE, 2000 Me, XP; Macintosh OS 9.1 or later

Weight and Dimensions

maximum scan area	12.2" x 17.2" (310mm x 437mm)
width	25.8" (656mm)
depth	18.0" (458mm)
height	6.2" (158mm)
weight	28.7 lb (13 kg approx.)
