Epson Expression 10000XL Service Manual

Expression 10000XL Revision A
PRODUCT DESCRIPTION Error Handling 19
1.5 Error Handling
NOTE: Refer to Chapter 3 "Troubleshooting" for details.
Table 1-4. Error Detail and Corrective Action List
Classification Indication Cause Corrective action Recovery
Receivable
command
Command error READY LED lit
ERROR LED lit
An undefined command or undefined
command parameter was received.
Return NACK and wait for the next
command. When a wrong command
parameter was received, ignore that value and
hold the original value.
Receive a correct command to recover
from the error.
-
Communication
error
Unsupported (as SCSI is not provided)
Fatal error READY LED flashing
ERROR LED flashing
The lamp is blown.
The main unit is faulty.
The optional equipment is abnormal
or unsupported board was inserted.
Extinguish the lamp and stop operation.
Set Bit 7 of the status bit.
Switch power off and then on again.
Press the RESET switch.
Send the initialization command
(ESC@).
ESC, ESC f
ESC @, FS F
Option error READY LED lit
ERROR LED extinguished
Cover open, paper empty, etc. Set Bit 7 of the status bit. Remove the cause of the error to recover
from the error.
-

Epson Expression 10000XL Specifications

Resolution

optical resolution	2400 dpi
maximum resolution with Micro Step Drive technology	2400 x 4800 dpi
interpolated resolution	12, 800 x 12, 800 dpi

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without optional unit	45W
power consumption operating with optional unit	55W
power consumption sleep mode without optional unit	6W

Operating Environment

operating temperature	41ºF to 95ºF (5ºC to 35ºC)
operating humidity	10% to 80% (no condensation)
storage humidity	10% to 85% (no condensation)

Interface and Connectivity

interface	USB 1.1/2.0, IEEE 1394 (FireWire), optional Ethernet
system compatibility	Windows 98SE, 2000 Me, XP; Macintosh OS 9.1 or later

Weight and Dimensions

maximum scan area	12.2" x 17.2" (310mm x 437mm)
width	25.8" (656mm)
depth	18.0" (458mm)
height	6.2" (158mm)
weight	28.7 lb (13 kg approx.)
