Epson Expression 10000XL Service Manual

Expression 10000XL Revision A
PRODUCT DESCRIPTION Product Features 9
1.1 Product Features
1.1.1 Product Features
This ES-10000G is a fast A3 color image scanner optimum for business/office
applications. The main features are given below.

High image quality

Resolution : 2400 x 4800 dpi (Micro-step drive)

Pixel Depth : 16-bit input, 16-bit output

Maximum OD value : 3.8D

Focus control : Auto focus by right-angle mirror motion

Wide scan area

Document tray scan : 12.2 x 17.2 inch (310 x 437mm)

ADF scan : 11.7 x 17.0 inch (297 x 432mm)

TPU scan : 12.2 x 16.5 inch (309 x 420mm)

Fast scan

1200 dpi scan mode

2400dpi scan mode

Transparent document scan mode

Support of scan navigation button

Scan start (for network connection)

Scanner application software start (for local connection)

A wide variety of interfaces

Standard
USB 2.0 (HS)
IEEE1394 (6pin)

Option
Extended slot (supported ID = 0, 1: E Supported)

Command level

ESC/I-B8

FS

Option:

ADF (Same ADF as used with ES-7000H)

TPU

N/W card
Line Art About 2.7msec/line
256 levels of Grayscale about 2.7msec/line
Color About8.0msec/line
Line Art About5.3msec/line
256 levels of Grayscale About5.3msec/line
Color About16.0msec/line
Positive film Approx. 16.0msec/line
Negative film Approx. 16.0msec/line

Epson Expression 10000XL Specifications

Resolution

optical resolution	2400 dpi
maximum resolution with Micro Step Drive technology	2400 x 4800 dpi
interpolated resolution	12, 800 x 12, 800 dpi

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without optional unit	45W
power consumption operating with optional unit	55W
power consumption sleep mode without optional unit	6W

Operating Environment

operating temperature	41ºF to 95ºF (5ºC to 35ºC)
operating humidity	10% to 80% (no condensation)
storage humidity	10% to 85% (no condensation)

Interface and Connectivity

interface	USB 1.1/2.0, IEEE 1394 (FireWire), optional Ethernet
system compatibility	Windows 98SE, 2000 Me, XP; Macintosh OS 9.1 or later

Weight and Dimensions

maximum scan area	12.2" x 17.2" (310mm x 437mm)
width	25.8" (656mm)
depth	18.0" (458mm)
height	6.2" (158mm)
weight	28.7 lb (13 kg approx.)
