Epson Expression 10000XL Service Manual

Expression 10000XL Revision A
PRODUCT DESCRIPTION Basic Specifications 13
1.2.6 Electrical Noise Resistance

Static electricity:
Panel section : 10kV
Metal section : 7kV/150p, F150Ω
1.2.7 Environmental Conditions
1.2.8 Reliability

Main unit
MCBF : Carriage reciprocating movement = 100,000 times
1.2.9 Operating Conditions

Dust : General house/office level
(Avoid extremely dusty environment)

Luminous intensity : Avoid direct sunlight and vicinity of light source.
1.2.10 Document Conditions

Reflective documents : Documents with smooth surface, such as
photos and prints.

Transparent documents

Supported document type : Positive film
Negative film

Document size : Any size. The following films are available
by use of film holders:
5mm strip film
35mm slide film
Brownie size film (up to 6 x 18mm)
4 x 5 inch film
Table 1-1. Environmental Conditions
Temperature
Humidity
(Non-condensing)
Operating 5 - 35°C 10 - 80%
Storage -25 - 60°C 10 - 85%

Epson Expression 10000XL Specifications

Resolution

optical resolution	2400 dpi
maximum resolution with Micro Step Drive technology	2400 x 4800 dpi
interpolated resolution	12, 800 x 12, 800 dpi

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without optional unit	45W
power consumption operating with optional unit	55W
power consumption sleep mode without optional unit	6W

Operating Environment

operating temperature	41ºF to 95ºF (5ºC to 35ºC)
operating humidity	10% to 80% (no condensation)
storage humidity	10% to 85% (no condensation)

Interface and Connectivity

interface	USB 1.1/2.0, IEEE 1394 (FireWire), optional Ethernet
system compatibility	Windows 98SE, 2000 Me, XP; Macintosh OS 9.1 or later

Weight and Dimensions

maximum scan area	12.2" x 17.2" (310mm x 437mm)
width	25.8" (656mm)
depth	18.0" (458mm)
height	6.2" (158mm)
weight	28.7 lb (13 kg approx.)
