Epson Expression 10000XL Service Manual

Expression 10000XL Revision A
PRODUCT DESCRIPTION Basic Specifications 11

2400dpi scan mode

Transparent document scan mode

Interfaces :

USB2.0(1 pc.)

IEEE1394 serial bus interface (1 pc.)

Extended slot (supported ID = 0, 1: E Supported)

Light source : High-intensity xenon fluor lamp

Switch :

OPERATE SW

Scan Navigation SW

Indication : LED red, green

Option

Auto document feeder (ADF)

TPU

N/W card

Noise : 45dB or less (TPU is also operating)
1.2.2 General TPU Specifications

System : Light source-moving, document-fixed scanning system

Light source : High-intensity xenon fluorescent lamp for positive film and
high-intensity xenon fluorescent lamp for negative film

Document size : Max. 309 x 420mm (12.2 x 16.5 inches)

Color separation : Color separation by color CCD

Sub scanning step: 4800dpi(micro-step driver)
1.2.3 Detail Specifications
1.2.3.1 Firmware, Software

Command level : ESC/I command (B8 level)
FS command

Image processing functions

Zoom : 50 to 200% (can be set in 1% increments)

Gamma correction
Output-by-output correction : 5 type as standard
2 types for CRT (A,B)
3 types for printer (A,B,C)
User-defined correction table can be set (1 type)

Color correction
Output-by-output correction : 4 type as standard
Wire dot printer
Thermal printer
Ink jet printer
Color monitor (CRT)
User-defined correction can be set (1 type)
Lightness correction : 7 levels
Line Art About5.3msec/line
256 levels of Grayscale About 5.3 msec/line
Color About 16.0 msec/line
Positive film About 16.0 msec/line
Negative film About 16.0 msec/line

Epson Expression 10000XL Specifications

Resolution

optical resolution	2400 dpi
maximum resolution with Micro Step Drive technology	2400 x 4800 dpi
interpolated resolution	12, 800 x 12, 800 dpi

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without optional unit	45W
power consumption operating with optional unit	55W
power consumption sleep mode without optional unit	6W

Operating Environment

operating temperature	41ºF to 95ºF (5ºC to 35ºC)
operating humidity	10% to 80% (no condensation)
storage humidity	10% to 85% (no condensation)

Interface and Connectivity

interface	USB 1.1/2.0, IEEE 1394 (FireWire), optional Ethernet
system compatibility	Windows 98SE, 2000 Me, XP; Macintosh OS 9.1 or later

Weight and Dimensions

maximum scan area	12.2" x 17.2" (310mm x 437mm)
width	25.8" (656mm)
depth	18.0" (458mm)
height	6.2" (158mm)
weight	28.7 lb (13 kg approx.)
