Epson Expression 10000XL Service Manual

Expression 10000XL Revision A
TROUBLE SHOOTING Action on Troubles 31
Figure 3-7. Fluor-lamp of TPU doesn’t light.
Start
Is the
Connector CN5 on the
TPU Main Board
connected?
Is the Harness
connected to the TPU
Main Board and TPU
Carriage?
Are the
Connectors CN2,
CN102 on the TPU
Inverter Board
connected?
Is the
Fluorescent Lamp
securely installed on
the TPU Inverter
Board?
Replace the TPU Main
Board.
Reinstall the Lamp on
the TPU Inverter
Board.
Connect the
Connectors.
Connect
the Connector.
Connect the Harness.

Epson Expression 10000XL Specifications

Resolution

optical resolution	2400 dpi
maximum resolution with Micro Step Drive technology	2400 x 4800 dpi
interpolated resolution	12, 800 x 12, 800 dpi

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without optional unit	45W
power consumption operating with optional unit	55W
power consumption sleep mode without optional unit	6W

Operating Environment

operating temperature	41ºF to 95ºF (5ºC to 35ºC)
operating humidity	10% to 80% (no condensation)
storage humidity	10% to 85% (no condensation)

Interface and Connectivity

interface	USB 1.1/2.0, IEEE 1394 (FireWire), optional Ethernet
system compatibility	Windows 98SE, 2000 Me, XP; Macintosh OS 9.1 or later

Weight and Dimensions

maximum scan area	12.2" x 17.2" (310mm x 437mm)
width	25.8" (656mm)
depth	18.0" (458mm)
height	6.2" (158mm)
weight	28.7 lb (13 kg approx.)
