Epson GT-30000 Service Manual

A3 Size Color Flat Bed Scanner GT-30000 Revision A
PRODUCT OUTLINE Specifications 12
1.2.3 Electrical Specifications
"
Rated Voltage: AC100-120V
AC220-240V
"
Input voltage: AC100-120V±10%
AC220-240V±10%
"
Rated Current: 1.0A (Input AC100-120V)
0.5A (Input AC220-240V)
"
Rated Frequency Range: 50-60 Hz
"
Input Frequency Range: 49.5-60.5 Hz
"
Power consumption: Operation ave.65W (Scanner only),
ave.90W (with ADF)
Save energy mode max.12W (without Using
Extend IF Slot)
"
Insulation resistance: 10 MW at 500VDC (between AC line and
chassis)
"
Dielectric strength: AC1.2kV,1min (between AC Line and
chassis)
1.2.4 Safety, EMC, EPA
"
Safety
!
UL1950 (+D3): USA
!
CSA C22.2 NO.950 (+D3): Canada
!
EN60950 (VDE)
!
IEC60950 (PROSTEST,PSB)
"
EMC
!
FCC Part15 Subpart B Class B: USA
!
CSA C108.8 Class B: Canada
!
AS/NZS3548 Class B: Australia
!
CISPR Pub22 Class B: Korea
!
CNS13438 Class B: Taiwan
"
CE Marking
!
Low Voltage Directive 73/23/EEC EN60950
!
EMC Directive 89/336/EEC EN55022 Class B
EN61000-3-2
EN61000-3-3
EN 50082-1
IEC 60801-2/801-3/801-4
"
EPA Energy Star
1.2.5 Resistance to Electric Noise
"
Static Electricity: Panel =10kV
Metal = 7kV
1.2.6 Environmental Specifications
"
Temperature: Operating = 5 to 35°C
Storage = -25 to 60°C
"
Humidity: Operating = 10 to 80%
(no condensation)
Storage = 10 to 85%
(no condensation)
1.2.7 Reliability
"
MCBF 200,000 cycle Life600,000 cycle (Scanner only)
"
MTBF 100,000 sheets (ADF)
1.2.8 Operating Conditions
Dust: Ordinary office or home conditions. Extreme dust
should be avoided.
Illumination: Operation under direct sunlight or near strong light
source is not guaranteed and should be avoided.

Epson GT-30000 Specifications

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without ADF	65W
power consumption operating with ADF	90W
power consumption standby without optional unit	12W

Operating Environment

temperature operating	41ºF to 95ºF (5ºC to 35ºC)
humidity operating	10% to 80% (no condensation)
humidity storage	10% to 85% (no condensation)

Scanning Specifications

optical resolution	600 x 1200 dpi with Micro Step Drive™ technology
maximum resolution	9600 x 9600 dpi with interpolation
effective pixels	7020 x 10200 pixels (600 dpi)
color depth internal	36 bits per pixel
color depth external	24 bits per pixel (selectable)
grayscale depth internal/external	12 bits per pixel
grayscale depth external	8 bits per pixel
scanning speed at 1600 dpi, draft mode, color	0.79 msec/line (approx.)
scanning speed at 1600 dpi, draft mode, grayscale	0.39 msec/line (approx.)
scanning speed at 1600 dpi, draft mode, art	0.39 msec/line (approx.)

Weight and Dimensions

maximum read area	11.7" x 17.0" (297mm x 432mm)
width	25.9" (658mm)
depth	19.2" (488mm)
height	10.0" (254mm)
weight	66 lb (37.5 kg approx.)
