APPENDIX Connector Pin Assignment 68
7.1 Connector Pin Assignment
Connectors used on the electrical circuit boards are summarized in the table
below.
7.1.1 Connector Summary
Table 7-1. Connector Summary
Board
CN
No.
Function Ref.
PBA-MAIN
CN1 - -
CN2 For connection with Wide SCSI I/F Table 7-2 on page 69
CN3 For connection with Normal SCSI I/F Table 7-3 on page 70
CN4 For connection with ADF/TPU Option Table 7-4 on page 71
CN5
For connection with PBA-CONNECT
Board
Table 7-5 on page 71
PBA-
CONNECT
CN1 For connection to PBA-LAMP Board Table 7-6 on page 73
CN3 For connection to the motor Table 7-7 on page 74
CN4 For connection to Open Sensor Table 7-8 on page 74
CN5 For connection to PWS-POWER Table 7-9 on page 74
CN6 For connection to PWB-PANEL Table 7-10 on page 74
CN7 For connection to PWB-MAIN Table 7-5 on page 71
CN8
Connector for optional IEEE 1394 I/F
board
Table 7-11 on page 75
CN9
For connection to document size
sensors
Table 7-12 on page 76
CN10
For connection to document size
sensors
Table 7-13 on page 76
CN11 - -
CN13 For connection to PBA-CCD Board Table 7-14 on page 76
PWS-
POWER
CN1 For connection with AC inlet -
CN2
Power supply line for PBA-MAIN
Board
Table 7-9 on page 74
CN3 Power supply line for fan -
PBA-
LAMP
CN1
For connection with PBA-CONNECT
Board
Table 7-7 on page 74
CN2
For connection with POWER SUPPLY
Board
Table 7-15 on page 77
POWER
SUPPLY
CN1 For connection with PBA-LAMP Board Table 7-15 on page 77
CN2 For connection with the lamp -
Table 7-1. Connector Summary (continued)
Board
CN
No.
Function Ref.
