Epson GT-30000 Service Manual

A3 Size Color Flat Bed Scanner GT-30000 Revision A
OPERATING PRINCIPLES Electrical Circuit Operations 28
The different levels of VDC are distributed to corresponding mechanisms, as
shown in "Table 2-4 DC Output Power":
2.3.2 Size sensor operation
The scanner is equipped with six document size sensors which automatically
determine the size of the document when scanning is carried out, so that only
the actual document area is scanned (no preview operation is necessary).
However, the document sizes that can be recognized in this way are limited to
A3 (landscape), B4 (portrait and landscape), A4 (portrait and landscape) and
B5 (portrait and landscape).
Table 2-4. DC Output Power
Output VDC Application
+5 V Logic and document size sensor power lines
+24 V
 Motor drive power source
 Power source for the lamp (inverter)
+12 V
+12 V production
(Drives the cooling fan for the metal, shielded tray that contains
the PBA-MAIN and PWS-POWER boards.)
+3.3 V Logic power lines

Epson GT-30000 Specifications

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without ADF	65W
power consumption operating with ADF	90W
power consumption standby without optional unit	12W

Operating Environment

temperature operating	41ºF to 95ºF (5ºC to 35ºC)
humidity operating	10% to 80% (no condensation)
humidity storage	10% to 85% (no condensation)

Scanning Specifications

optical resolution	600 x 1200 dpi with Micro Step Drive™ technology
maximum resolution	9600 x 9600 dpi with interpolation
effective pixels	7020 x 10200 pixels (600 dpi)
color depth internal	36 bits per pixel
color depth external	24 bits per pixel (selectable)
grayscale depth internal/external	12 bits per pixel
grayscale depth external	8 bits per pixel
scanning speed at 1600 dpi, draft mode, color	0.79 msec/line (approx.)
scanning speed at 1600 dpi, draft mode, grayscale	0.39 msec/line (approx.)
scanning speed at 1600 dpi, draft mode, art	0.39 msec/line (approx.)

Weight and Dimensions

maximum read area	11.7" x 17.0" (297mm x 432mm)
width	25.9" (658mm)
depth	19.2" (488mm)
height	10.0" (254mm)
weight	66 lb (37.5 kg approx.)
