Epson GT-30000 Service Manual

A3 Size Color Flat Bed Scanner GT-30000 Revision A
ADJUSTMENTS Adjustments Using the Special Software 60
4. The current setting data rear from the EEPROM will be displayed in the
respective areas.
5. The EEPROM data can then be edited.
5.3.3.2 Japanese/English Display Select Button
Click this button to toggle the display language for the dialog box between
Japanese and English.
5.3.3.3 Changing the Scanner Model
1. Select the scanner model from the scanner model selection list.
2. Click Write.
5.3.3.4 Adding a new scanner model
1. If you would like to add a new scanner model, enter the name of the new
scanner model in the additional model display area.
2. After entering the model name, click Add. The new scanner model will then
be added to the end of the scanner model selection list.
The new scanner model can then be selected in the same way as other
scanner models.
5.3.3.5 Deleting the Selected Scanner Model
1. Select the scanner model that you would like to delete so that the model
name appears in the additional model display area.
2. After checking that the selected scanner model is correct, click Delete.
3. The selected scanner model will then be deleted from the scanner model
selection list.
5.3.3.6 Resetting the number of scans to zero
1. Click 0 Clear. The 0 Clear confirmation message box will be displayed.
2. To reset the value, click OK. To cancel the operation, click Cancel. The
data will only be reset to zero if you click OK.
C A U T I O N
!
Due to the identity of the program, if you input some
data to any area and click "write" button, the life
counter of scanning frequency and ADF paper
sheets fed will be reset automatically. Therefore, it is
recommended to take a memo before you edit any
area.
!
Prepare an note to write down each scanners life
counter when you service or repair a scanner.
C H E C K
P O I N T
Be sure to write the data to the EEPROM after each
editing change has been made.
C H E C K
P O I N T
Be sure to set the scanner model after replacing the
main circuit board.
C A U T I O N
Note that when the number of scans (cumulative
life) is reset to zero, the previous value will not be
retained.

Epson GT-30000 Specifications

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without ADF	65W
power consumption operating with ADF	90W
power consumption standby without optional unit	12W

Operating Environment

temperature operating	41ºF to 95ºF (5ºC to 35ºC)
humidity operating	10% to 80% (no condensation)
humidity storage	10% to 85% (no condensation)

Scanning Specifications

optical resolution	600 x 1200 dpi with Micro Step Drive™ technology
maximum resolution	9600 x 9600 dpi with interpolation
effective pixels	7020 x 10200 pixels (600 dpi)
color depth internal	36 bits per pixel
color depth external	24 bits per pixel (selectable)
grayscale depth internal/external	12 bits per pixel
grayscale depth external	8 bits per pixel
scanning speed at 1600 dpi, draft mode, color	0.79 msec/line (approx.)
scanning speed at 1600 dpi, draft mode, grayscale	0.39 msec/line (approx.)
scanning speed at 1600 dpi, draft mode, art	0.39 msec/line (approx.)

Weight and Dimensions

maximum read area	11.7" x 17.0" (297mm x 432mm)
width	25.9" (658mm)
depth	19.2" (488mm)
height	10.0" (254mm)
weight	66 lb (37.5 kg approx.)
