Epson GT-30000 Service Manual

A3 Size Color Flat Bed Scanner GT-30000 Revision A
APPENDIX ASP List 92
7.5 ASP List
Table 7-16. Major ASP List
Drawing No. Name
1 WS sems screw M4X8
3 IT tapping tite screw M3X6
5POWER-SW-CAP
7 MIRROR-SL
8 Pan screw M4X10
9 GUIDE-WH-CRG-1
10 COVER-INV
11 GUIDE-WH-CRG-2
12 SHEET-COVER-M
14 ASSY-FRAME-UPPER
15 SPL-GLASS-B
16 CAP
17 COVER-OPTION
18 ASSY-SELECT-PAPER-X
19 ASSY-COVER-LOWER
20 LEG-16X16X3.2
21 ASSY-CVR-UPPER-SUB
22 GUIDE-OPTICAL
23 SW-SCANNER
24 SPC-SCANNER-SW
25 GUIDE-SW-SCANNER
26 PLT-ADF-5
27 PLT-ADF-1
28 GUIDE-HINGE-R
29 GUIDE-HINGE-L
30 GUIDE-HINGE-L-PIN
31 Spring pin 2X8
32 SPC-GUIDE
33 GUIDE-HINGE-L-SUB
34 GUIDE-FFC
35 BKR-PCB-HP
36 Tapping tite S-tite
37 FILM-CRG1
38 SHEET-BKT-COVER-PCB
39 EY-3A-1081
40 ASM-INLET
41 ASM-PANEL
42 ASM-SIZE1
43 ASM-SIZE2
44 ASM-PWR
45 ASM-OPEN
46 PWS-PXZ26014-D
47 LMP-UXFL-10W37P
48 PBA-LAMP
49 ASSY-FFC2
50 ASSY-FFC1
52 ASSY-MOTOR-UNIT
53 ASSY-MAIN-NO-ROM
54 ASSY-ROM
55 PWS-POWER
56 UAMS-05-2
57 PBA-CONNECT
58 PBA-PANEL
59 ASSY-PS
60 M4X12 Wave screw
61 SCR4X12 Wave screw
62 Binding screw M3X10
63 PLT-MAGNET
Table 7-16. Major ASP List
Drawing No. Name

Epson GT-30000 Specifications

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without ADF	65W
power consumption operating with ADF	90W
power consumption standby without optional unit	12W

Operating Environment

temperature operating	41ºF to 95ºF (5ºC to 35ºC)
humidity operating	10% to 80% (no condensation)
humidity storage	10% to 85% (no condensation)

Scanning Specifications

optical resolution	600 x 1200 dpi with Micro Step Drive™ technology
maximum resolution	9600 x 9600 dpi with interpolation
effective pixels	7020 x 10200 pixels (600 dpi)
color depth internal	36 bits per pixel
color depth external	24 bits per pixel (selectable)
grayscale depth internal/external	12 bits per pixel
grayscale depth external	8 bits per pixel
scanning speed at 1600 dpi, draft mode, color	0.79 msec/line (approx.)
scanning speed at 1600 dpi, draft mode, grayscale	0.39 msec/line (approx.)
scanning speed at 1600 dpi, draft mode, art	0.39 msec/line (approx.)

Weight and Dimensions

maximum read area	11.7" x 17.0" (297mm x 432mm)
width	25.9" (658mm)
depth	19.2" (488mm)
height	10.0" (254mm)
weight	66 lb (37.5 kg approx.)
