Epson TM-C3500 Series - Paper Feed Adjustment

Chapter 3 Handling
129
3
Paper Feed Adjustment
Allows you to specify the following:
Settings Description
Cut Position
Adjustment
Adjust the cut position. The unit is 1/180 inch. You can make adjustments in the
range of -63 to 63.
Print Start Position
Adjustment
(Vertical Direction)
Adjust the print start position (vertical direction). The unit is 1/180 inch. You can
make adjustments in the range of -63 to 63.
Print Start Position
Adjustment
(Horizontal
Direction)
Adjust the print start position (horizontal direction). The unit is 1/180 inch. You
can make adjustments in the range of -4 to 4.
The [dot] - [mm] - [inch] conversions for 180 dpi are as follows.
1dot - 0.1411 mm - 0.0055inch
2dot - 0.2822 mm - 0.0111inch
3dot - 0.4233 mm - 0.0166inch
4dot - 0.5644 mm - 0.0222inch
5dot - 0.7055 mm - 0.0277inch
6dot - 0.8466 mm - 0.0333inch
7dot - 0.9877 mm - 0.0388inch
8dot - 1.1288 mm - 0.0444inch
9dot - 1.2700 mm - 0.0500inch
10dot - 1.4111 mm - 0.0555inch
