Epson TM-C3500 Series - Media Arrangement; Media Arrangement When Feeding Media for Printing from the First Sheet

Chapter 3 Handling
167
3
Media arrangement
Media arrangement when feeding media for printing from the first sheet
Roll paper
This can be used with the following media forms.
•Continuous paper (Blackmark)
•Die-cut label (Blackmark)
•Die-cut label (Gap)
•Transparent die-cut label
Loading Paper
When feeding paper, bring the edge of the roll paper between the autocutting position and the
edge of the paper ejection table, then close the roll paper cover.
Method for arranging the media
•Continuous paper (Blackmark)
Place the edge of the first black mark in a position 172.5 mm {6.791”} or more from the edge of
the roll paper, and do not place a black mark before there.
Autocutting position
Area for the edge
of the paper
Edge of the paper
Edge of the paper
ejection table
Head
Paper feed
direction
Black mark position
172.5 mm {6.791” } or more
