Chapter 6 Appendix
207
5
Media type Plain / Matte
Media source Fanfold paper
Paper width 50 to 108 mm {1.97 to 4.25"}
Black mark width 13 mm {0.51"} or more
Black mark length 4 mm {0.16"} or more
(with a width of at least 4 mm around)
Center of a black mark 8.5 mm 1 mm {0.33 0.039"}
Gaps between black marks 8 to 304.8 mm {0.32 to 12.0"}
Paper thickness 0.124 to 0.128 mm {0.0047 to 0.005"}
Gaps of perforated line 203.2 to 304.8 mm {8 to 12"}
Form of perforated line Plain media : 1 mm {0.039"} uncut, 5 mm {0.2"} cut
Fine media : 1 mm {0.039"} uncut, 5 mm {0.2"} cut
PET film : 0.6 mm uncut, 8.4 mm cut
Number of folds 500 or less
Do not use the paper with a hole or cutout.
Autocutting on the perforated lines may generate minute paper dust, causing machine
problems. Also, autocutting ahead of the perforated line may cause problems when
feeding paper. Therefore, autocutting must be performed 0.5 mm to 1 mm {0.02 to
0.039"} behind the perforated line.
Black marks must position away at least 0.5 mm {0.02"} from the perforated line.
The perforated lines on both sides of the paper edge must be left uncut.
Make sure to keep the same position of the black marks to the perforated lines (position
that can be detected by black mark sensor) when inserting the paper from either side in
order to use the paper inserting from reverse direction.
