Epson WF-C8690 User Manual

35
5 The LCD screen
6 The log out button
7
The help button
8
The stop button
9
The Interrupt button
10
The Reset button
11 The Paper Setting button
12 The Job/Status button, the Error light, and the Data light
13 The numeric keypad
14 The Contacts button
15 The C clear button
Status Icon Information
Parent topic: Using the Control Panel
Status Icon Information
Your product displays status icons on the LCD screen for certain product status conditions. Select the
icon to view or change the current network settings.
Icons Description
Displays additional information or instructions, such as loading paper or placing a
document.
Displays the Printer Status screen.
Quiet Mode is enabled. Noise is reduced during printing, but the print speed may be
reduced. Select this icon to change the settings.
Quiet Mode is disabled. Select this icon to change the settings.
The Mute setting is enabled. The printer does not make any sound when you press buttons
on the control panel.
Displays the Fax Data Information screen.

Epson WF-C8690 Specifications

General

Print Resolution	4800 x 1200 dpi
Max Print Size	13" x 19"
Print Speed	24 ppm (black), 24 ppm (color)
Automatic Duplex Printing	Yes
Scanner Type	Color Flatbed / ADF
Scan Resolution	1200 x 2400 dpi
ADF Capacity	50 sheets
Fax Speed	33.6 kbps
Mobile Printing	Epson Connect, Apple AirPrint, Google Cloud Print, Mopria
Display	4.3" color touchscreen
Ink Colors	Cyan, Magenta, Yellow, Black
Print Technology	PrecisionCore
Monthly Duty Cycle	75, 000 pages
Connectivity	USB, Ethernet, Wi-Fi
Paper Capacity	330 sheets standard / 1, 830 sheets maximum
