Apache AS1010
Tire Pressure (Cold)
12.4 x 28” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 psi [207 kPa]
320/85R38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 psi [283 kPa]
380/80R38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 psi [241 kPa]
380/90R46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 psi [338 kPa]
Lug Nut Torque
Front 12.4 x 28” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180 lb-ft [244 N•m]
All Front 38” tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 315 lb-ft [427 N•m]
All Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 460 lb-ft [624 N•m]
Wet System Capacities
Product Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 850 or 1000 gallons [3218 or 3785 liters]
Rinse Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 gallons [189 liters]
Hydraulic Pump Output . . . . . . . . . . . . . . . . . . . . . . . . 2450 psi [169 bar] @ maximum engine rpm
Component Lubrication Capacity
Quarts [Liters]
Filter Part Number
Engine Oil Lucas 15W-40 Mag-
num Motor Oil
16 [15] 201450241
Engine Coolant KostGuard Universal
Antifreeze 50/50
23 [21.8] ----
Engine Air Filter ---- ---- 201300116
Engine Safety Air Filter ---- ---- 201300117
Transmission (ITL/JCB)* Lucas Universal
Hydraulic Fluid
16 [15] 300000101
Differential (Rear Axle) Lucas 80/90 Gear Oil 26.4 [25] ----
Planetary Lucas 80/90 Gear Oil 2.2 [2] ----
Rear Drop Box Lucas 80/90 Gear Oil 21 [20] ----
Brake Reservoir Lucas Universal
Hydraulic Fluid
as required ----
Engine Fuel Diesel 100 Gallons [379 Liters] Engine Mounted:
Standard: 201450242
Separator: 201450243
Hydraulic System Lucas Universal
Hydraulic Fluid
30 Gallons [113.5 Liters] Filter: 840000013
Strainer: 840000010**
Strainer: 840000011**
Front Suspension Lucas Universal
Hydraulic Fluid
as required ----
Pressure Steering ---- ---- Filter: 840000048
A/C System R134a 3 Lbs. ----
Cab Charcoal Filter ---- ---- 490003650
Cab Recirculating Filter ---- ---- 490006660
* - Check transmission (ITL/JBC) fluid level with the engine turned off and the transmission fluid hot.
See ”Check Transmission Fluid Level” on page 5-10.
** - The hydraulic fluid strainers are mounted in the hydraulic reservoir and may be cleaned and
reused. See ”Clean Hydraulic Fluid Strainers” on page 5-20.
NOTE: Any oil and fluid substitutions must meet or exceed recommended fluid specifications.
NOTE: A Funk transmission is optional equipment on the AS1010. If your AS1010 is equipped with the
optional Funk transmission, see the Apache 1210 Component/Lubrication sheet.
