WET SYSTEM OPERATION
4-17
Spraying
Make sure the product, rinse, and foam marker
tanks are filled. See the appropriate tank filling
instructions in this section.
Level the booms and boom tips using the tilt
and unfold switches. See Boom Operation for
details.
Set the boom height using the boom rack
switch. See “Operating Booms” on page 4-13
Open the sump valve (1) on the underside of
the product tank.
IMPORTANT: Always read and follow all
chemical labels and follow all federal and state
laws when applying chemicals.
Close the rinse tank valve (1).
Set the flush/agitation knob (2), shown in the
“CLOSED” position, to “AGITATION”.
Open the product valve (3).
The product strainer features a 50 mesh
screen which should be checked and cleaned
after every 50 hours of operation or as
needed.
NOTE: Depending on the chemicals being
applied, it may be necessary to substitute the
50 mesh screen with a more coarse strainer.
See the chemical manufacturer’s instruc-
tions for complete details.
