LUBRICATION AND MAINTENANCE
5-8
Boom Outer Breakaway (if equipped)
There are six boom outer breakaway grease
fittings (1), three on each boom tip. The left
side is shown.
Flush Wet System
Drain and flush the product tank and wet sys-
tem after use and when changing chemicals.
See “Flushing Product Tank” on page 4-24.
See “Flushing Wet System” on page 4-26.
Check Tire Pressure
Check the tires for proper inflation pressure
and damage. Tire pressures are listed on the
back cover of this manual. Replace tires that
have cuts or bubbles.
Check the rims for cracks and other damage.
Replace damaged rims.
Check Engine Oil Level
NOTE: If the engine has been running, shut
off and wait 10 minutes before checking oil
level.
The dipstick is located in the engine compart-
ment, on the left side of the engine.
Remove the dipstick and check the oil level.
The oil level should be within the hatched
area on the dipstick.
