LUBRICATION AND MAINTENANCE
5-15
After First 100 Hours
The following services must be performed after the first 100 hours of operation and repeated as pre-
scribed by the Apache Sprayer Service Interval Chart.
• Adjust Poly Tank Straps. See “Adjust Poly Tank Straps (if equipped)” on page 5-17.
• Replace Differential Fluid. See “Replace Differential Fluid” on page 5-19.
• Replace Hydraulic Fluid Filter. See “Replace Hydraulic Fluid Filter” on page 5-19.
• Replace Engine Oil and Filter. See “Replace Engine Oil and Filter” on page 5-23.
• Replace Transmission Fluid and Filter. See “Replace Transmission Fluid and Filter” on page 5-24.
Every 100 Hours
The following services must be performed after every 100 hours of operation of the Apache Sprayer.
Grease Driveline Components
The Apache Sprayer has a total of ten drive-
line grease fittings. Three of these fittings are
slip joint fittings and seven are U-joint fittings.
Apply an ample amount of lithium grease
through each of the fittings.
One slip joint grease fitting (1) is located
under the vehicle, between the transmission
and the rear axle.
A U-joint fitting is located at the transmission
output U-joint (not shown) and another fitting
(2) is located on the U-joint connected to the
slip joint.
A U-joint fitting (1) is located at the differential
input.
