Equipment Technologies APACHE AS1010 - Product Pump and Valves; Sump Valve; Rinse and Foam Tank

WET SYSTEM OPERATION
4-2
Product Pump and Valves
1. Product Pump
2. Rinse Tank Shutoff Valve
Shown in closed position.
3. Product Tank Shutoff Valve
Shown in open position.
Sump Valve
1. Product Tank Sump Valve
Shown in the open position.
Rinse and Foam Tank
1. Rinse Tank
2. Foam Concentrate Bottle
