VEHICLE OPERATION
3-16
Antenna Mounting Plate
A steel plate is mounted under the recess in
the roof of the cab (1) for magnetic base GPS
and radio antennas.
Raven Drive Shaft Speed
Sensor (Optional)
The optional Raven drive shaft speed sensor
is located just behind the carrier bearing on
the drive shaft.
Raven Radar Gun (Optional)
The Raven radar gun is located on the right
side of the vehicle, mounted under the bat-
tery box.
