VEHICLE OPERATION
3-15
Towing
IMPORTANT: Towing a machine with driveshaft in place or with a damaged transmission may
further damage the transmission.
IMPORTANT: DO NOT tow tractor if the rear differential has failed.
If the Apache Sprayer should become disabled and there is no engine, transmission, or differential fail-
ure, the vehicle may be towed for approximately 1 mile [1.6 km] at speeds less than 3 mph [4.8 km/h].
While towing the vehicle, the engine should be running at idle and the parking brake released.
If the Apache Sprayer should become disabled and the engine will not start, remove the drive shaft
between the differential and the transmission. The vehicle may be towed up to 1 mile [1.6 km] at speeds
less than 3 mph [4.8 km/h].
Hood Release
IMPORTANT: Do not allow the engine com-
partment hood to swing open freely. Damage
to the vehicle may result. Use the nylon strap
under the hood to control the opening of the
hood.
The engine compartment hood release is
located on the front of the vehicle at the bot-
tom of the grille.
Pull the lever to release the hood. Use the
nylon strap under the hood to control the
opening of the hood.
Battery
The batteries are located in the battery box
(1) on the right side of the vehicle.
Remove the four bolts and cover to access
the batteries.
1. Battery box
2. External positive and negative battery
posts.
