Equipment Technologies APACHE AS1010 - Filling Product Tank; Filling Rinse Tank

WET SYSTEM OPERATION
4-11
Filling Product Tank
Open the sump valve (1) on the underside of
the product tank.
Remove the cap from the product quick fill
inlet (1) and connect the hose from the nurse
tank to the inlet.
Close the rinse tank valve (2).
Open the product fill valve (3), shown in the
“CLOSED” position, and fill tank to desired
level.
When filling is complete, close the valve on
the nurse tank, then close the product fill
valve.
Disconnect the hose from the inlet and install
the quick fill inlet cap.
Filling Rinse Tank
Remove the cap from the foam / rinse quick
fill inlet (1) and connect the hose from the
nurse tank to the inlet.
Set the rinse knob (2), shown in the
“CLOSED” position, to “RINSE TANK FILL”.
IMPORTANT: Fill the tank slowly. Rapid
filling or overfilling may rupture the tank.
Open the valve on the nurse tank and fill to
desired level.
When filling is complete, close the valve on
the nurse tank, then set the rinse knob (2) to
“CLOSED”.
Disconnect the hose from the inlet and install
the inlet cap.
