WET SYSTEM OPERATION
4-12
Remove the lid on the top of the foam tank, add the
appropriate amount of foam concentrate, and install the
lid.
1. Optional Fence Row Nozzle
If your vehicle has optional fence row nozzles, they
are located near the end of each boom. The electric
control valve for nozzles is located on the rear boom
tank.
2. Optional Foam Marker Boot and Drop
If your vehicle is equipped with the LandMark injec-
tion foam marker, then the boot is located near the
end of each boom.
3. Foam Marker Mixing Chamber
The foam marker mixing chamber is located near the
end of each boom.
