WET SYSTEM OPERATION
4-13
Operating Booms
IMPORTANT: Do not fold or unfold the booms near power lines.
NOTE: Never fold or unfold the booms while the vehicle is moving over 5 mph.
NOTE: Never unfold booms with optional auto boom height control turned on.
Tilt to Remove Boom from Cradle
All Boom Sizes
On the T-handle, press the top of the left (1)
and right (2) boom tilt raise/lower switches to
tilt the boom and boom hangers (3) off of the
boom cradles (4).
Unfold Booms
IMPORTANT: Do not fold or unfold the
booms near power lines.
NOTE: Never fold or unfold the booms while
the vehicle is moving over 5 mph.
NOTE: The boom hangers must be tilted off
of the boom cradles before they can be
unfolded.
On the side console, press the top of the left
and right boom fold switches (1) until the
booms are fully extended. After the booms
are fully extended, the boom tips can be
unfolded.
