SPECIFICATIONS
AS1010
AS1210
Tank Capacity 850 gallons (1000 gallons optional) 1200 gallons
Engine 215 Cummins Tier III
655 ft-lb@1500 rpm
275 Cummins Tier III
655 ft-lb@1500 rpm
Transmission Standard: ITL Powershift 6-speed
torque converted
Optional: Funk Powershift 6-speed
torque converted
Funk Powershift
6-speed, torque converted
Speeds ITL 6-Speed
1st 0-5 mph
2nd 0-8 mph
3rd 0-11 mph
4th 0-18 mph
5th 0-29 mph
6th 0-36 mph
Funk Transmission
1st 0-5 mph
2nd 0-8 mph
3rd 0-11 mph
4th 0-18 mph
5th 0-29 mph
6th 0-36 mph
1st 0-5 mph
2nd 0-8 mph
3rd 0-11 mph
4th 0-18 mph
5th 0-29 mph
6th 0-36 mph
Brakes Internal, wet disc self-adjusting
Suspension Front Axle: Center oscillation with independent hydraulic accumulation.
Rear Axle: Patented hydraulic load suspension with compensating anti-sway con-
trol, self-adjusting for diminishing/increasing load.
Crop Clearance 36”, 42”, 48” 48”
Axles Narrow fixed: 88” to 90”, 100” to 101”, 102” -
104”, 105” to 114”. 48” crop clearance only.
Wide adjustable: 120” to 144” (Optional hydraulic
adjust)
Wide adjustable: 120” to
144”. (Optional hydraulic
adjust)
Final Drive Standard: Fairfield all gear drop box
Optional: ITL/JCB planetary gear set
Fairfield all gear drop box
Cab ET custom ET custom
Weight
17,329 lbs. (approximate)
Dry weight with poly tank.
20,170 lbs. (approximate)
Dry weight with stainless
steel tank.
Width 144” (12’)
Height 144” (42” crop clearance)
Length 27’
Booms 60’, 75’, 80’, 90’, 100’
60/80, 60/90
Boom Height 14” to 74” (42” crop clearance); 20” to 80” (48” crop clearance)
Wheel Base 173” (14’5”)
Tires Standard Front: 12.4 x 28
Standard Rear: 380/90R46
Optional Front: 380/80R38
Optional Rear: 320/90R46
Standard Front: 380/80R38
Standard Rear: 380/90R46
Turning Radius 17’
Fuel Capacity 100 gallons
Product Pump Hypro 9306S HM1C, hydraulically driven centrifugal pump
