LUBRICATION AND MAINTENANCE
5-25
Funk Transmission (AS1210 and
optionally equipped AS1010)
The transmission fluid drain plug is located
under the vehicle on the left side of the trans-
mission fluid pan.
Remove the drain plug (1) and drain the
transmission fluid into a suitable container.
Dispose of the fluid properly.
Install the drain plug.
Funk Transmission (AS1210 and
optionally equipped AS1010)
The transmission fluid filter is located under
the vehicle on the left side of the transmis-
sion.
Turn the filter counter-clockwise to remove.
Dispose of the filter properly.
IMPORTANT: Do not overtighten the filter.
Damage to the seal can result.
Lubricate the seal on the transmission fluid
filter, Part Number 300100110, and install.
Tighten the filter, by hand, 3/4 to 1-1/4 turns
after the seal contacts the filter housing.
The fluid capacity of the transmission is
approximately 16 quarts [15 liters].
IMPORTANT: DO NOT overfill the transmis-
sion fluid. Overfilling can damage the trans-
mission or cause the transmission to
malfunction.
IMPORTANT: Use only Lucas Universal
Hydraulic Fluid.
Use a funnel to fill the transmission fluid at
the transmission dipstick tube on the left side
of the engine.
