2 Configuration of the Machine
For better visibility of subjacent functions, covers have been removed or opened before
taking pictures. In standard operating mode all covers have to be in place at any time.
2.1 Configuration of Machine and Modules
Since the configuration includes also adjustments, the safety regulations written in the
Startup & Safety manual must be read before starting the tasks.
2.1.1 Introduction
The machine Fox itself is a very flexible and multipurpose equipment. Therefore it is necessary to
configure it for a specific task or function. The configuration includes also some necessary
adjustments.
2.1.2 Tools and Material
For an effective and efficient machine configuration, the following tools and material have to be
provided:
Required Tools / Material
Tools:
USB mouse and USB keyboard
1 metal ruler
1 vacuum meter
Screwdrivers and Allen keys in different sizes
Nozzles:
4x Nozzle 4
1x Nozzle 6
1x Nozzle 3
