Essemtec Fox - Reject bin Emptying; Contaminated Areas Cleaning (Dispensing)

Preventive Maintenance
Fox Maintenance © Essemtec AG 4-7
0000074/05
/ March 31, 2017
4.3.4 Reject Bin Emptying
Overview
Empty the reject bin containing all components
which could not be placed on PCB.
Note:
When replacing the reject bin, make sure
that the bin is properly engaged in the
opening. Serious damage can occur if the
reject bin is improperly seated (collision
risk).
4.3.5 Contaminated Areas Cleaning (Dispensing)
Medium Trash emptying
Empty the medium trash or exchange the plastic
cup containing all the medium trash.
• G2: Cup 0.04 l (transparent), SP61/CP02
Note:
When replacing the medium trash, make
sure that the cup is properly engaged in
the opening. Damage can occur if the
cup is improperly seated (collision risk).
