Essemtec Fox - Height Laser Cleaning; Air Maintenance Unit Checking

Preventive Maintenance
Fox Maintenance © Essemtec AG 4-27
0000074/05
/ March 31, 2017
4.6.3 Height Laser Cleaning
The height laser is an optional module. If the machine is not equipped with a laser, skip this
chapter.
Apperture cleaning
The apperture of the laser has to be cleaned with
a lint free cloth. Do not use any cleaning
material.
Note:
If the prerequisits are observed, the laser
should be switched off.
In any case, never star into laser beam.
4.6.4 Air Maintenance Unit Checking
Check Liquid Catchment
Check the catchment (3) for any liquid. If any,
take away or turn off the compressed air before
dumping the air maintenance unit.
Unscrew the release valve and press it (1). Empty
the liquid catchment (3) completely.
