Essemtec Fox - Materials and Tool-Kits; Materials and Tool-Kits Overview

Fox Maintenance © Essemtec AG 1-1
0000074/05
/ March 31, 2017
1 Materials and Tool-Kits
1.1 Materials and Tool-Kits Overview
The materials and tool-kits described in this chapter are necessary for:
• Configuration
• Calibration
• Preventive Maintenance
• Corrective Maintenance
CAL-SET12 Tool-Kit for P&P Head Maintenance
Part number: CAL-SET12
The purpose of this set is to recalibrate the Pick
& Place Head. The kit consists of:
• Glass plate 65 x 50 mm
• Aluminum calibration plate 15 x 15 mm
