Preventive Maintenance
4-30 © Essemtec AG Fox Maintenance
0000074/05
/ March 31, 2017
Remove Head Covers
From the front side of the machine, loosen and
remove the 2 fixing screws of the cover.
Remove the cover.
On top of the head, loosen and remove the 3
fixing screws of the top cover (see picture).
Carefully remove the cover.
