There are four positions where to apply grease
(see picture), two on the front rail and two on
the back rail.
First of all, clean all the positions with a soft and
lint-free cloth, if necessary lightly dampened
with Isopropanol or Ethanol.
For a better access to the lubricating points, the
clamping mechanism must be in the upper
position.
Switch on the compressed air (SUP) at the
Compressed Air Maintenance Unit.
Produce
Production Settings
Clamp PCB to bring the clamping mechanism to
the upper position.
By means of the black brush (9 mm wide), apply
to each of the four positions the grease
Kluebersynth BEM 34-32 (SP26/HG08), see
picture. Do not overgrease.
Wipe away excessive grease.
Unclamp PCB.
Close this maintenance procedure 'Conveyor
Clamping Checking / Lubricating'
