J LCD CONTRAST ADJUST: The thumb wheel adjusts the contrast
of the LCD.
K MULTI-FUNCTION KNOB: The rotary encoder is used to select
and adjust various settings. It is also a push switch.
L KNOB MODE INDICATORS: These LEDs indicate the rotary
encoder mode. There are 4 modes:
SELECT – which is used to indicate that the encoder will select from
a list of items.
INC/DEC – which is used to indicate that the encoder will increment
or decrement a value.
JOG/SHUTTLE – which is used to indicate that the encoder is used
to move to a forward or backward within an call.
SPEED – which is used to indicate that the encoder is used to adjust
the speed of a call.
M SPEAKERS: The DIR911t has internal speakers for listening to
playback.
N LEVEL: This knob is used to adjust the volume of the speakers (or
the headphones if they are currently in use)
O HEADPHONE JACK: The DIR911t supports a single set of stereo
headphones via this 3.5mm stereo phono jack. When headphones are
plugged into the unit, the speakers are muted.
P RE-RECORD JACK: The DIR911t provides a Re-Record line level
output via a 3.5mm stereo phono jack. This output is a copy of the
signal provided to the speakers/headphones (before the level
adjustment via the LEVEL knob (Legend #N).
Q MONITOR JACK: The DIR911t provides a Monitor line level
output that via a 3.5mm stereo phono jack. The monitor output
contains an exact copy of the current line selected.
