DIR911T User Guide
78
Pin Description
TIP Left
RING Right
SLEVE Ground
Table 12: Front Panel Re-Record Connector Pin Description
Headphone Output Connector
There is a 3.5mm Tip-Ring-Sleeve (TRS) connector that provides the headphone output
signal. This connector is used to connect the unit to headphones. The mating connector
for this jack is shown in Figure #64 and the pin description is shown in Table #13.
Tip
Ring
Sleve
Figure 64: Front Panel Headphone Connector Pin Diagram
Pin Description
TIP Left
RING Right
SLEVE Ground
Table 13: Front Panel Headphone Connector Pin Description
