DIR911T User Guide
42
Line #1
Line Input Gain: +12.0dB -29.6dBu
Aux Input Gain: 0.0dB -47.3dBV
CURSOR DONE
Figure 20: Telephone and AUX Input Gain Screen
This setting is used to boost or attenuate the telephone or AUX input level before being
digitized by the DIR911t. The current line signal level is shown for convenience.
Use the encoder to select the gain value. Press the CURSOR soft key to move between
the Telephone and Auxiliary gain. Press the DONE soft key to effect the change and exit
the menu.
Automatic Gain Control Setup
The Automatic Gain Control (AGC) setup screen is used to enable, disable, and adjust the
various parameters for the both the input and output AGC. The screen is shown in Figure
#21.
Line #1
REC. AGC off Max Gain 20dB
PLAY AGC off Max Gain 20dB
CURSOR DEFAULT DONE
Figure 21: AGC Screen
The AGC can be enabled or disabled. The Gain setting is the upper limit on the AGC
gain.
Use the encoder to adjust the selected parameter. Press the CURSOR soft key to select
the parameter to adjust. Press the DEFAULT soft key will reset the parameters to their
power-on default values. Press the DONE key to exit the menu.
Monitor and Re-Record Output Level Adjust
The monitor and re-record output level adjustment screen is shown in Figure #22.
