and the HOOK setting in the line activation mechanism screen is enabled the DIR911t
will activate the line and start recording. For convenience, the voltage for the current line
(as well as its current state) is shown.
Use the encoder to select the threshold value. Press the DONE soft key to effect the
change and exit the menu
Test External Relay Closure Activation
The external indication test screen is shown in Figure #29.
Line# 1: EXT I/O pin # 7, GND pin # 5
line 1 line 2 line 3 line 4
DISABLE DISABLE DISABLE DISABLE
DONE
Figure 29: Test External Closure Screen
This screen is used to show the state of the external connections that may affect the unit’s
decision to start recording a call.
Press the DONE soft key to exit the screen.
Audible Beep Level
The audible beep level screen is shown in Figure #30.
Line #1
The BEEP is currently: ENABLED
Beep Gain: -20dB
DISABLE DONE
Figure 30: Audible Beep Level Screen
This screen is used to adjust the level of the audible beep that is placed on the telephone
line when the line is actively recording.
To Next Page
