DIR911T User Guide
34
• The current line selected is shown on the 5x7 LED matrix.
• The current call number and total message count are shown in the upper right
hand corner of the screen.
• Directly below the date and time is the current status of the unit. The status field
gives you a direct indication of what the unit is currently doing and each entry is
described in Table #3
Ready The unit is idle and is neither playing back nor recording a call
from the currently selected line.
Recording The unit is recording a call. The lines recording are shown after
the Recording indicator.
Playing The unit is playing back a previously recorded call. The
percentage of speed-up/slow-down is shown following the
Playing indicator.
Paused The unit is playing back a previously recorded call but playback
has been paused.
Rew The unit is rewinding the current call by a factor displayed after
the Rew indicator.
Fwd The unit is fast-forwarding the current call by a factor displayed
after the Fwd indicator.
Table 3: Status Field Descriptions
• Directly below the message counts is the date and time of the currently selected
call. When no call is currently stored in the unit, it displays <No Call>.
• The third line is used to display dialed DTMF digits, recovered Caller ID digits,
ALI and/or ANI digits and the current call length. The message number of the
most recent call is shown in Ready mode.
• The final line contains four soft keys: LIVE, PREV CALL, NEXT CALL, and
RESTORE. These are described below:
While in the main mode, four soft keys are used: LIVE, NEXT CALL, PREV CALL,
and RESTORE.
