DIR911T User Guide
60
Split Mode
The total call count screen is shown in Figure #50.
SPLIT MODE: DISABLED
DONE
Figure 46: Split Mode Screen
This screen is used to enable/disable split mode operation. Depending on how the
DIR911t is licensed, turning the knob will enable split 6 or 8 channel operation. See the
Split Mode Chapter for more information.
Import/Export System Configuration
The Import/Export System Configuration screen, shown in Figure #47, provides a way to
import and/or export the current DIR911t system configuration. Importing/Exporting is
done via a USB key. Exporting a configuration creates a file on the USB key named
dir911t.cfg which contains the entire box configuration. Importing a configuration
requires a file named dir911t.cfg which contains a previously exported DIR911t
configuration and requires a system reboot for the imported settings to take effect.
IMPORT/EXPORT the system configuration
IMPORT EXPORT DONE
Figure 47: RAID Import/Export System Configuration Screen
Insert a USB key into the USB socket and press the IMPORT key to import saved
configuration (remove the key when the unit returns prompts you to reboot the unit).
Insert a USB key into the USB socket and press the EXPORT key to export the current
configuration (remove the key when the unit returns to the System Mode screen). Press
the DONE soft key to exit this menu.
