DIR911T User Guide
66
Include calls that start
between: 12-May-06 09:14:24
and: 12-May-05 09:14:24
CURSOR DEFAULT DONE
Figure 55: Date and Time Filter Screen
Use the CURSOR soft key to select the various date fields. The KNOB is used to change
the value of the currently selected field. The DEFAULT key will return the screen to the
default value (which is the current date to start and the current date minus 1 year to end).
Press the DONE key to exit back to the call filter setup screen.
Incoming Line Filter
The incoming line filter screen is used to constrain the search to include only calls that
were received on certain lines. The screen is shown in Figure #56
Include calls that were recorded on
Line 1 Line 2 Line 3 Line 4
YES YES YES YES
CURSOR DEFAULT MORE LINES DONE
Figure 56: Incoming Line Filter Screen
Use the CURSOR soft key to select the desired line to change. The KNOB is used to
change the value of the currently selected field. The DEFAULT key will return the
screen to the default value (which is all lines enabled i.e. set to YES). The MORE
LINES soft key toggles between Lines 1-4 and Lines 4-8 when split mode is enabled.
Press the DONE key to exit back to the call filter setup screen.
DTMF Digits Filter
The DTMF digit filter screen is used to constrain the search to include only calls that
were received that start with, contain, or end with a specified series of DTMF digits. The
screen is shown in Figure #57
