DIR911T User Guide
37
The system configuration menu is shown in Figure #10.
Please enter your password:
0000
CURSOR INCREASE DECREASE DONE
Figure 10: Password Screen
Use the encoder knob to increase and decrease the value. Pressing the encoder knob will
move the cursor one location to the right. Use the CURSOR soft key to move the cursor
one position to the right. Press the INCREASE key to increase the character at the cursor
by one. Press the DECREASE key to decrease the character at the cursor by one. Press
the DONE soft key to the system configuration menu (assuming the password is correct,
of course).
NOTE: The password screen will bypassed when the unit security setting is in the LOW
state. If this is the case, the user will be placed directly in the system screen.
NOTE: the factory default setting for the DIR911t is in high security mode with a
default password of: 0000. This means on initial configuration you can simply press the
DONE soft key.
At this point you are now in the system screen. This is shown in Figure #11.
SELECT CONFIGURATION OPTION:
Save to USB Drive
(call(s) to USB thumb drive)
ENTER NEXT OPT PREV OPT DONE
Figure 11: System Screen
It is from this screen that all the various system configuration settings are changed.
Turning the encoder will select the parameter (or parameter group) and press the ENTER
soft key (or push the encoder) to enter the parameter’s configuration menu. Using the
NEXT OPT or PREV OPT keys will move about the parameters as well. Press the
DONE soft key to return to the main mode.
The following sections detail each configuration option.
