DIR911T User Guide
43
Monitor output gain: -0.0dB
Re-Record out. gain: -0.0dB
DONE
Figure 22: Monitor and Re-Record Output Level Adjust Screen
The Monitor and Re-Record output screen allows for adjusting the output gain for the
respective output. This is true analog gain in that it is applied after the D/A conversion
process.
Use the encoder to select the level. Press the CURSOR soft key to select between
Monitor and Re-Record. Press the DONE soft key to effect the change and exit the
menu.
Sampling and Compression
The sampling and compression setup screen is shown in Figure #23.
Sample Rate: 8.0kHz
Data Compression: PCM Linear
CURSOR DONE
Figure 23: Telephone Activation Level Screen
This screen determines the sample rate and the compression type used to record and
compress the calls.
The compression types are detailed below:
