DIR911T User Guide
46
Method Description
LINE Voice activity on the line (the threshold is set via the VOX Recording
Activation menu) can cause recording to begin.
AUX Voice activity on the AUX (the threshold is set via the VOX
Recording Activation menu) can cause recording to begin.
HOOK Hook Voltage on the telephone line (the threshold is set via the
Adjust Off Hook Activation menu) can cause recording to begin.
EXTERNAL Grounding of the appropriate pin (see Table #19) can cause recording
to begin.
Table 6: Line Activation Methods
Use the encoder to scroll through the choices. Each can be explicitly enabled or disabled.
Press the CURSOR soft key to select the source. Press the DONE soft key to effect the
change and exit the menu.
VOX Record Activation Threshold
The VOX recording activation level setup screen is shown in Figure #26.
Line #1
LINE: -10dBu Rec. DISABLE -29.3dBu
AUX: -10dBV Rec. DISABLE -47.4dBV
CURSOR DONE
Figure 26: VOX Record Activation Threshold Screen
This setting is used by the DIR911t to decide if there is enough voice activity on the
telephone or auxiliary line to start recording. If at any time the voice level on the
telephone line is above this value and the “line” setting in the line activation mechanism
screen is enabled the DIR911t will activate the line and start recording. If at any time the
auxiliary level is above this value and the “aux” setting in the line activation mechanism
screen is enabled the DIR911t will activate the line and start recording.
