DIR911T User Guide
55
Ethernet: DHCP
Addr: 0.0.0.0 Mask: 0.0.0.0
Gtwy: 0.0.0.0 DNS: 0.0.0.0
CURSOR DEFAULT DONE
Figure 37: Ethernet Setup Screen
This screen is used to set the IPv4 addresses for the Ethernet port on the unit. There are
three settings for Ethernet: OFF, DHCP, and MANUAL. The off setting disables the
Ethernet port. The DHCP setting uses the Dynamic Host Configuration Protocol to query
an DHCP server for the unit’s Ethernet settings. The Manual setting allows the user to
specify the addresses manually.
Use the encoder to change the various screen parameters. Use the CURSOR soft key to
move the cursor around to the various parameters. Press the DEFAULT soft key to
return the Ethernet screen to its default settings. Press the SYSTEM key to exit the
menu without changing anything (for example, to view the IPv4 address without
reconfiguring the network port).
Email Address Setup
The email address setup screen is shown in Figure #38.
Calls: Auto:off
Reports: 00Hr
Status
CURSOR CLEAR TEST DONE
Figure 38: Email Address Setup Screen
The DIR911t is able to send email when certain system alarms are triggered or to forward
actual call data as attachments. This screen configures the email addresses to which these
messages are sent is entered. The three email addresses configured on this screen are:
Calls, Reports, and Status. The Calls email address is the address to which a call is sent
(from the RECALL mode screen). The Reports email address is where periodic DIR911t
reports are sent. The status email address is the address to which the DIR911t internal
system log (a log of all activity pertaining to the operation of the box) is sent.
