211
EVINRUDE ICON REMOTE CONTROL SYSTEM
ICON REMOTE CONTROL SYSTEM FAULT MESSAGES
10
151: Shift Actuator
Sensor Fault (fault
code 108 will appear
with this fault code).
Shift actuator sensor
cannot determine
gear position.
All LED indicators
flash until control
levers and shift actua-
tors are in NEUTRAL.
Afterwards, only the
NEUTRAL indicator
LED associated with
the engine that has a
fault flashes.
RFI due to excessive
spark plug gap, dam-
aged or worn spark
plugs.
Shift actuator harness
is damaged.
Shift actuator position
sensor is faulty.
ESM is faulty.
• Check spark plug condition.
Gap and install new spark
plugs.
• Check harness from ESM to
shift actuator for damage.
• Swap a known good shift
actuator.
• Swap a known good ESM
152: Shift Actuator
Motion Fault (no
other fault code
appears with this
fault code).
Shift is unable to
move to FORWARD
or REVERSE gear or
NEUTRAL position.
FORWARD, NEU-
TRAL or REVERSE
indicator LED flashes
to indicate which gear
position it is not able to
move to.
Engine stalled while
underway.
Shift actuator has an
open circuit.
Shift actuator is not cali-
brated.
Shift linkage is dam-
aged.
Shift actuator is faulty
• Retry shifting
• Turn master power/
key switch OFF and then
back to RUN position to
reset system.
• Check shift actuator harness
for damage.
• Calibrate shift actuator.
• Swap a known good shift
actuator.
107: Control Commu-
nication Error (fault
code 108 will appear
with this fault code).
Outboard EMM can-
not communicate
with ICON remote
control.
All LED indicators
flash until control
levers and shift actua-
tors are in NEUTRAL.
Afterwards, only the
NEUTRAL indicator
LED associated with
the engine that has a
fault flashes.
Buss cable or ICON
hub is not connected or
damaged.
ESM harness is faulty
or damaged
10 Amp fuse for out-
board engine harness
has failed (only if fuse
failed with engine run-
ning).
Battery voltage is low.
• Turn master power switch
OFF and back to RUN posi-
tion to reset system.
• Check buss cables and
ICON hubs from remote
control to ESM for damage.
• Swap known good buss
cables or ICON hubs.
• Check harness from ESM to
outboard EMM for damage.
• Check 10 Amp fuse. Check
engine harness for damage.
• Check condition of batteries,
battery connections and/or
battery switches.
Fault Code:
Description
LED
Indicators
Possible Cause
Fault Description/
Troubleshooting Procedure
