212
EVINRUDE ICON REMOTE CONTROL SYSTEM
ICON REMOTE CONTROL SYSTEM FAULT MESSAGES
109: Control Hard-
ware Fault (fault
code 108 will appear
with this fault code).
Control lever posi-
tion sensor failure.
All LED indicators
flash until control
levers and shift actua-
tors are in NEUTRAL.
Afterwards, the LED
indicator associated
with the faulty control
lever will turn OFF.
Remote control is faulty.
• Turn master power/
key switch OFF and then
back to RUN position to
reset system.
• Swap a known good remote
control.
110: Trim Switch
Module Communica-
tion Fault (no other
fault code appears
with this fault code).
ICON remote control
cannot communicate
with trim and tilt
switch panel (3, 4, or
5 engines only).
None
Trim and tilt switch har-
ness is faulty.
Trim and tilt switch
panel is faulty.
• Turn master power/key
switch OFF and then back to
RUN position to reset sys-
tem.
• Check harness from trim
and tilt switch panel to
remote control for damage.
• Swap a known good trim
and tilt switch panel.
111: ESM Communi-
cation Fault (fault
code 108 will appear
with this fault code).
ICON remote control
cannot communicate
with ESM.
All LED indicators
flash until control
levers and shift actua-
tors are in NEUTRAL.
Afterwards, only the
NEUTRAL indicator
LED associated with
the engine that has a
fault flashes.
Buss cable or ICON
hub is not connected or
damaged.
ESM harness is dam-
aged or faulty.
Battery voltage is low.
• Turn master power/
key switch OFF and then
back to RUN position to
reset system.
• Check buss cables and
ICON hubs from remote
control to ESM. Swap
known good buss cables or
ICON hubs.
• Check harness from ESM to
outboard EMM.
• Check condition of batteries,
battery connections and/or
battery switches.
Fault Code:
Description
LED
Indicators
Possible Cause
Fault Description/
Troubleshooting Procedure
