5.2 HMI (housing cover)
1 HMI cover
2 Connection to the Backboard 4
3 USB 1
4 Ethernet 1
5 RS485 terminal strip
6 RS485 switch bus termination/Symmetry
7 Battery Insulator
NOTICE
Figure shows the HMI including optional expansion
board
5
4
3
2
1
6
7
